Garden & outdoor equipment

Tow-behind garden trailers

Garden utility trailers with tow bars, box bodies and multiple wheel configurations.

Reference16 catalog model references

Request a quote View model specifications

MOQ, customization and lead time depend on the selected model and order.

Reference specifications

Tow-behind garden trailers reference specifications
Model selection	Compare the reference table below
Ordering	Model, quantity and destination specified with each inquiry

Specifications shown are catalog references. Your quotation confirms the current model, drawing and agreed requirements for the order.

Quotation requirements

Specify your application.

Model and required quantity
Destination and delivery requirements
Material, finish and configuration
Packaging, labeling and technical documentation

Send your requirements ↗

Models & specifications

16 catalog references

Compare catalog references below. Select a reference to include it in your inquiry; current specifications and options are confirmed with your quotation.

Tow-behind garden trailers: catalog model comparison
Model	Catalog load capacity	Wheel specification	Body size (L × W × H)	Inquiry
BTC002A	450 kg 992 lb	16″ × 4.00-8 pneumatic	1350 × 815 × 970 mm 53.1 × 32.1 × 38.2 in	Request quote
BTC002B	450 kg 992 lb	16″ × 4.00-8 pneumatic	1858 × 867 × 710 mm 73.1 × 34.1 × 28 in	Request quote
BTC002C	350 kg 772 lb	16″ × 4.00-8 pneumatic	1480 × 830 × 770 mm 58.3 × 32.7 × 30.3 in	Request quote
BTC003	700 kg 1,543 lb	16″ × 6.50-8 pneumatic	1650 × 920 × 1070 mm 65 × 36.2 × 42.1 in	Request quote
BTC006	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1615 × 825 × 700 mm 63.6 × 32.5 × 27.6 in	Request quote
BTC007A	500 kg 1,102 lb	16″ × 6.50-8 pneumatic	2200 × 780 × 920 mm 86.6 × 30.7 × 36.2 in	Request quote
BTC008	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1615 × 935 × 860 mm 63.6 × 36.8 × 33.9 in	Request quote
BTC008A	680 kg 1,499 lb	16″ × 8.00-7 pneumatic	2000 × 1070 × 760 mm 78.7 × 42.1 × 29.9 in	Request quote
BTC008B	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1440 × 770 × 800 mm 56.7 × 30.3 × 31.5 in	Request quote
BTC010	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1995 × 790 × 990 mm 78.5 × 31.1 × 39 in	Request quote
BTC011	250 kg 551 lb	16″ × 4.00-8 pneumatic	1600 × 940 × 815 mm 63 × 37 × 32.1 in	Request quote
BTC012	680 kg 1,499 lb	18″ × 9.50-8 pneumatic	2200 × 1285 × 1050 mm 86.6 × 50.6 × 41.3 in	Request quote
BTC013	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1660 × 740 × 980 mm 65.4 × 29.1 × 38.6 in	Request quote
BTC014	500 kg 1,102 lb	16″ × 4.00-8 pneumatic	1610 × 720 × 1060 mm 63.4 × 28.3 × 41.7 in	Request quote
BTC015	350 kg 772 lb	16″ × 4.00-8 pneumatic	1470 × 630 × 940 mm 57.9 × 24.8 × 37 in	Request quote
BTC016	500 kg 1,102 lb	16″ × 8.00-7 pneumatic	1380 × 740 × 880 mm 54.3 × 29.1 × 34.6 in	Request quote

Product selection & purchasing

Sourcing Tow-behind garden trailers

Applications & product range

Tow-behind trailers support grounds-maintenance and landscape-material transport. Compare box dimensions, catalog load references and wheel sizes before selecting a configuration.

Configuration & purchasing requirements

Provide towing-equipment details, hitch dimensions, terrain and intended load. These are garden-equipment references; request a matching hitch drawing and operating limits.
